  • EQUAL Pit Type Weighbridge, Truck Scale, 120 MT, 18.0 M X 3.0 M

EQUAL Pit Type Weighbridge, Truck Scale, 120 MT, 18.0 M X 3.0 M

SKU: UEWB / PT - 8
This type of weighbridge / Truck scale is most suitable where the excavation work for foundation is difficult or construction of pit is expensive. Since the structure is above ground level, vehicles can approach the weighbridge only from two directions where the ramps are provided. This type of weighbridge requires more space. In Pitless Type Weighbridge RCC ramp work must be required at least 3 meters for both sides for easy movement of vehicle.
More Information
Made In India

Description

Weighbridge & Truck Scale Highlights

Weighbridge in this category are designed for trucks that are used in normal highway transportation, Mining Indusrtry & Warehouses. The modular design of these products allow for customization to suit your exact needs. Choose from a wide range of steel and concrete deck truck scale designs that use our Premium load cell technology to provide proven performance and exceptional durability.

Durable weighbridges for long truck scale life

Every new weighbridge design undergoes rigorous life-cycle testing. Over a couple of months, each weighbridge design is tested to a minimum of one million cycles - or 20 years of heavy use. This testing helps guarantee the best quality and longest scale life.

Accessory

Cup & Ball Type Load Cell, Remote Display, Junction Box, Keyboard, Printer & USB Port

Proven Weighbridge Design
Unique design helps direct the pressure of a heavy load away from areas that would be fatigued by stress

Product Specifications

Type of Weigh Bridge
Pit Type
Capacity (Tonnes)
120 MT
Resolution(Kg)
20Kg
Number of Load Cell
8
Load Cell Technology
Double Ended Shear Beam
Model No
UEWB / PT - 8
Printer Make
TVS
Software
Avilable
Junction Box
8-Way
Remote Display port
Yes
×
